Specifications:   CATALOGUE

• Heavy duty steel construction ensuring increased stability.
• Expandable framework
• 4 stage memory storage height adjustment using a push button
• Auto stop function if the desk encounters a obstacle on the way down.
• Push button activation
• Double motor drive assembly
• Dynamic load push: 600N each leg
• Maximum lift capacity is 120kg
• Speed at full load: 35mm/S
• Lowest position: 700mm (Not including top)
• Highest position: 1,200mm
• Minimum extension length: 1,000mm
• Minimum depth of the desktop recommended is 600mm
• Base (Foot) length: 700mm (600mm option, Indent Only)
• Available as standard in White , with Black and Grey optional
• Sizes = 2,100mm, 1,800mm, 1,500mm, 1,200mm x 800mm (Or any size between.  Minimum depth of the desktop recommended is 600mm)

• All adjustments for the height are infinitely locking
• 25mm thick table top is a suggested thickness
• Solid steel frame construction with a powder coated finish
• Some assembly required
• Electrical Approval No. AZ 69020747

Box size:  = 350W x 1070D x 200H  (0.8m3)  Weight =  31kg.
